“Improved Oil Recovery & EOR using Biological Enzymes”

ENZYME WATERFLOODING DRIVE PROCESS

Since GreenZyme® is completely mixable in produced water, GreenZyme® can be diluted even to below 500 ppm level, and still be effective in "releasing" crude oil from sand surfaces in the formation, GreenZyme® is then an useful agent in all secondary oil-recovery drive process. The waterflooding procedure is as follow: 1) Quantity of GreenZyme® needed: In a normal waterflooding drive, produced water is pumped from the injector wells with pressure towards the receiver- wells, which are the producer wells. Typical production engineer will estimate how many tons of produced water is needed to inject, and also estimate how many tons of crude oil this cycle of injection will produce before repeating the next cycle of waterflooding drive. Under normal waterflooding drive, calculate the quantity of GreenZyme® needed at 500 ppm strength from the total tons of water used, say 16-drums of GreenZyme® concentrate in this cycle. The production engineer has the number of drums of GreenZyme® needed (16 drums). 2) How to apply the required number of GreenZyme® drums into this waterflooding drive? You do not need to use an external tank to dilute the 16-drums of GreenZyme® to 500 ppm level before injection. Why? Because we can use the underground formation as a mixing-tank, since GreenZyme® is easily and instantly mixable with produced-water in the underground formation. How to do this? Say we need 16-drums of GreenZyme® concentrate for this drive, we propose a 4-steps dilution-injection stage, each stage contains 4-drums of GreenZyme® concentrate:   Step 1: Dilute the first 4-drums of GreenZyme® concentrate to 10% strength using an external tank and produced-water, pump this 10% GreenZyme® into formation, followed by the first part of 1/4 total of regular produced-water injection. Step 2: Repeat step 1 above, dilute the second 4-drums of GreenZyme® concentrate to 10% strength using an external tank and produced-water, pump this 10% GreenZyme® into formation, followed by the second part of 1/4 total of regular produced-water injection. Step 3: Repeat step 1 above, dilute the third 4-drums of GreenZyme® concentrate to 10% strength using an external tank and produced-water, pump this 10% GreenZyme® into formation, followed by the third part of 1/4 total of regular produced-water injection. Step 4: Repeat step 1 above, dilute the final 4-drums of GreenZyme® concentrate to 10% strength using an external tank and produced-water, pump this 10% GreenZyme® into formation, followed by the fourth part of 1/4 total of regular produced-water injection. After all 16-drums of GreenZyme® injection is finished, resume normal crude oil production. Please notice this: Significant crude oil increase in waterflooding production wells will happen only after the injection of produced-water + GreenZyme® eventually reaches the producing oil wells. This may happen in weeks, sometimes in months, depending on how far away the distance between injection well and the producing well and also the geological formation-profile underground. What is the difference by using GreenZyme® in waterflooding drive versus without use of GreenZyme® at all? The differences are as follow: a) The injection-cycle using GreenZyme® will produce significantly more crude oil than the cycle without GreenZyme®. b) The injection-cycle using GreenZyme® will extend the period of time crude oil increment will last. c) The pumping pressure is much less (i.e. using less pumping pressure means less energy costs) with GreenZyme® than the one without, and the total amount of liquid capable to be injected into the formation is also much greater than the one without GreenZyme®.

Fluid is injected at an Injection Well

Injected Fluid moves through the Oil Reservoir

After interacting with GreenZyme®, Mobilized Oil is Extracted

GreenZyme® for Waterflooding Systems
